特性

具有良好的平整性，导热缓冲性，使产品成型好，填充性能和结合性更好

产品应用

软性电路板行业，电热片，电池导电线等电子产品加工

表面材料

硅胶

表面颜色

朱红色

耐温

175 °C ～200°C

硬度

60±5shore A

比重

1.07g/cm3

厚度

2.3mm

一般规格

410mm*570m (宽*长)

硅胶延伸率

550%

拉扯强度

9MPa

使用温度

175 °C ～200°C

使用寿命

5000~8000次或六个月（以贵司实际压合参数为准，温度与压力越低，使用寿命越长）

产品功能

便于快压热盘离形
压着时起缓冲作用
装置于下热盘
硅胶可以使温度更均匀分布表面，避免作业者烫伤
铁板坚固，不易变形，使用寿命更长

注意事项

热盘表面必须平整无刮伤，安装时须尽量平贴于热盘表面
储存时间 (6个月 保存温度：15-25℃ 保存湿度：≤65%RH )

Properties

Heat conduction, heat resistance, high temperature resistance, good thermal conductivity(various thicknesses are available)

Applications

Insulation materials for heat dissipation of electronic components such as semiconductors, heat-dissipating protective materials for hot-pressing engineering, and heat-dissipating protective materials for heating elements.

Material

Silicone

Color

Scarlet

Temperature resistance

175 °C ～200°C

Hardness

60±5shore A

proportion

1.07g/cm3

Thickness

2.3mm

Product size

410mm*570mm( Width*Length )

Silicone elongation

550%

Tensile strength

9MPa

Operating temperature

175 °C ～200°C

Life long

5000~8000 times about 6 month (dependence on the temperature and pressure)

Function

Setup on hot press machine.
Silicone can buffer between device and hot plate when machine pressed on.
Silica gel allows the temperature to be more evenly distributed to the surface, avoiding burns

Notice

The surface of the hot plate must be flat and free of scratches. It should be placed on the surface of the hot plate as much as possible during installation.
Storage time (6 months storage temperature: 15-25 ° C Preservation humidity: ≤ 65% RH)
